OVERVIEW

Collection of wall recessed luminaires for exterior applications. Designed for low mounting heights with downward asymmetric light distribution.
Low luminance with the light source regressed inside the luminaire and shielded from all viewing angles.
Recessed application with metal back box to be installed during concrete forming or to be fastened to the wall structure before the building cladding.

Exceptional European build quality with high corrosion resistant finish. Robust marine grade die-cast aluminum construction with stainless steel fasteners and factory sealed micro-prismatic glass diffuser.







FEATURES


Recessed application with back box

Square or rectangular design

4 body sizes

High efficiency  Osram LEDs

High efficiency electronic driver > 50,000 H

Operating temperature -30°C / +30°C

IP65, UL Listed for wet location

Grey, anthracite, white, black or bronze

5 year limited warranty

SPECIFICATIONS



Power   4 / 11 / 12.5 / 25  watts

Output   18 / 28 / 200 / 370 lumens

Distribution  Downward asymmetric

Color  3000 / 4000 K

Cri   90

Controls   Consult the factory

Lumen maintenance : L70  50,000 Hours


APPLICATION IMAGES


MODELS / Downloads


MICROBLINKER 4W  18 lm Spec ►   IES/CAD ►

MICROBLINKER
4W  18 lm
Spec ►   IES/CAD ►

MINIBLINKER 11W 128 lm Spec ►   IES/CAD ►

MINIBLINKER
11W 128 lm
Spec ►   IES/CAD ►

BLINKER 12.5W 200 lm Spec ►   IES/CAD ►

BLINKER
12.5W 200 lm
Spec ►   IES/CAD ►

MEGABLINKER 25W  370 lm Spec ►   IES/CAD ►

MEGABLINKER
25W  370 lm
Spec ►   IES/CAD ►


ALSO AVAILABLE AS

S.6060W S.6060N S.6070W S.6070N S.6080W S.6080N S.6020W S.6060N
