OVERVIEW


Collection of walkover luminaires for exterior applications.





FEATURES


Available in 2 sizes

Round or square design

Walkover load 2000 lbs

Stainless steel 316L face place

UV resistant polycarbonate diffuser

Operating temperature -30°C / +30°C

IP67, UL Listed for wet location

5 year limited warranty

*Remote LED driver required

SPECIFICATIONS


Power  0.5 / 1.25 watts

Output  Up to 50 lumens

Distribution   7° / 30° / 70° / 90°

Color  3000 / 4000 K

Cri   80

Controls Consult factory

Lumen maintenance : L70  50,000 Hours


Application Images


MODELS / DOWNLOADS



NANOLED Square 1  1/8'' 0.5W Spec ►   IES/CAD ►   Instructions ►

NANOLED Square 1  1/8''
0.5W
Spec ►   IES/CAD ►   Instructions

NANOLED Square 1 3/4'' 1.25W Spec ►   IES/CAD ►   Instructions ►

NANOLED Square 1 3/4''
1.25W
Spec    IES/CAD ►   Instructions ►

NANOLED Square 1  3/4'' Transparent 1.25W Spec ►   IES/CAD ►   Instructions ►

NANOLED Square 1  3/4'' Transparent
1.25W
Spec ►   IES/CAD ►   Instructions


NANOLED Round 1  1/8'' 0.5W Spec ►   IES/CAD ►   Instructions ►

NANOLED Round 1  1/8''
0.5W
Spec ►   IES/CAD ►   Instructions

NANOLED Round 1 3/4'' 1.25W Spec ►   IES/CAD ►   Instructions ►

NANOLED Round 1 3/4''
1.25W
Spec ►   IES/CAD ►   Instructions ►

NANOLED Round 1 3/4'' Transparent 1.25W Spec ►   IES/CAD ►   Instructions ►

NANOLED Round 1 3/4'' Transparent
1.25W
Spec ►   IES/CAD ►   Instructions



Also AVAILABLE AS

S.3286W S.3286N S.3236W S.3236N S.3246W S.3246N S.3265W S.3265N S.3280W S.3280N S.3230W S.3230N S.3240W S.3240N S.3264W S.3264N
