OVERVIEW

Small aperture LED downlight for architectural lighting.
Only 1.5 aperture and 3" with trim, this compact luminaire delivers up to 1500 lumens.

The entire luminaire body is made of one piece die-cast aluminum, yielding maximum thermal performance to maintain the light output and color consistency during the life of the product.

FEATURES / specifications


Retrofit, new construction, insulated ceiling
or Chicago plenum applications.

Suitable for gypsum board, wood or thin metal ceiling

Fixed, wall washer or adjustable distributions

20-40 beams

LM80 tested Citizen LED

UL listed for damp location

5 year limited warranty

White trim with white-black / matt clear / anodized baffle

ASSEMBLED IN CANADA




Power   16 / 22 watts

Output  1100 / 1600 lumens

Distribution  15º / 25º / 40º / wallwasher

Color  3000 / 4000 K

Cri   80 / 90

Controls   TRIAC -0-10V

Lumen maintenance  L80 80,000 Hours


FIXED Downlight

Suitable for general lighting or accent lighting
The V-series downlight is available with 2 lumen packages of 1100 or 1600 lumens.
Sharp cut off for low brightness applications.





WALL WASHER

The wall washer optic provides a uniform asymmetric distribution.




ADJUSTABLE

The adjustable version is ideal for accent lighting.
Versatile design allow 30° tilt and 355° rotation of the entire optical assembly.
2 lumen packages of 1100 or 1600 lumens with 15º, 25º or 40º  beams.
