OVERVIEW


Collection of ceiling surface mounted luminaires for exterior applications.

Exceptional European build quality with high corrosion resistant finish. Robust marine grade die-cast aluminum construction with stainless steel fasteners and factory sealed glass diffuser.

FEATURES


Available in 3 sizes

Downlight adjustable 15º

Integral high efficiency electronic driver > 50,000 H

Operating temperature -30°C / +30°C

IP65, UL Listed for wet location

Aluminum gray or Anthracite gray

5 year limited warranty

SPECIFICATIONS


Power  6 / 16 / 27 Watts

Output  285 / 780 / 1275 lumens

Distribution  Downlight

Color  3000 / 4000 K

Cri   90

Controls Consult  factory

Lumen maintenance  L70  50,000 Hours


Application Images


MODELS / DOWNLOADS



MICROSLOT SQUARE  6W 285 lm  Spec  ►  IES/CAD  ►  Instructions  ►

MICROSLOT SQUARE
6W 285 lm
SpecIES/CADInstructions

MINISLOT SQUARE  16W 780 lm  Spec  ►  IES/CAD  ►  Instructions  ►

MINISLOT SQUARE
16W 780 lm
SpecIES/CADInstructions

SLOT SQUARE  27W 1275 lm  Spec  ►  IES/CAD  ►  Instructions  ►

SLOT SQUARE
27W 1275 lm
SpecIES/CADInstructions



ALSO AVAILABLE AS



S.3805W S.3805N S.3857W S.3867W S.3867N
